Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt

Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt
Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt

Large Image :  Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt

Product Details:
Place of Origin: CHINA
Brand Name: Bicheng
Certification: UL, ISO9001, IATF16949
Model Number: BIC-327.V1.0
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD9.99-99.99
Packaging Details: Vacuum bags+Cartons
Delivery Time: 8-9 working days
Payment Terms: T/T
Supply Ability: 5000PCS per month
Detailed Product Description
Base Material: Polyimide Layer Count: 1 Layer
PCB Thickness: 0.15mm ±0.05 PCB Size: 65 X 11.5mm=1PCS
Coverlay: Yellow Silkscreen: White
Copper Weight: 1oz Surface Finish: Immersion Gold



Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt

(Flexible printed circuits are custom-made products, the picture and parameters shown are just for reference)



Specifications

PCB SIZE 65 x 11.5mm=1PCS
Base Material: Polyimide
Number of Layers Single sided PCB
SMT YES
Through Hole Components no
LAYER STACKUP Copper ------- 35um(1oz)
Adhesive
PET
Minimum Trace and Space: 3.5mil/3.5mil
Minimum / Maximum Holes: 1.0mm/ 1.0mm
Final foil external: 1oz
Final foil internal: 0oz
Final height of PCB: 0.15mm ±0.05
Surface Finish Immersion Gold
Solder Mask Apply To: TOP
Solder Mask Color: Coverlay
CONTOUR/CUTTING Punching
Side of Component Legend Bottom
Colour of Component Legend White
Rigid area( Stiffener) PET
VIA None Plated Through Hole(NPTH)
FLAMIBILITY RATING UL 94-V0 Approval MIN.
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.



Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt 0

Flat PFC Strip Single Sided Flexible Printed Circuit With Immersion Gold For Contact Belt 1
