Dual Layer Flexible PCB Built on 1oz Polyimide With Carbon Ink and Immersion Gold For Laser Head
  • name
  • name
  • name
  • name

Dual Layer Flexible PCB Built on 1oz Polyimide With Carbon Ink and Immersion Gold For Laser Head

MOQ: 1PCS
Price: USD9.99-99.99
Standard Packaging: Vacuum bags+Cartons
Delivery Period: 8-9 working days
Payment Method: T/T
Supply Capacity: 5000PCS per month
Details Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
Bicheng
Certification
UL, ISO9001, IATF16949
Model Number
BIC-326.V1.0
Base Material:
Polyimide
Layer Count:
2 Layers
PCB Thickness:
0.15mm ±0.05
PCB Size:
113 X 120mm=32PCS
Coverlay:
Yellow Coverlay, Black Ink
Silkscreen:
White
Copper Weight:
1oz
Surface Finish:
Immersion Gold
Highlight:

1oz Polyimide Flexible PCB

,

Carbon Ink Flexible PCB

Product Description



Dual Layer Flexible PCB Built on 1oz Polyimide With Carbon Ink and Immersion Gold For Laser Head

(Flexible printed circuits are custom-made products, the picture and parameters shown are just for reference)



Specifications

PCB SIZE 113 x 120mm=32PCS
Base Material: Polyimide
Number of Layers Double sided FPC
SMT YES
Through Hole Components no
LAYER STACKUP Copper ------- 35um(1oz)
Adhesive
Polyimide
  Adhesive
  Copper ------- 35um(1oz)
Minimum Trace and Space: 4mil/4mil
Minimum / Maximum Holes: 0.3mm/ 2.0mm
Final foil external: 1oz
Final foil internal: 0oz
Final height of PCB: 0.15mm ±0.05
Surface Finish Immersion Gold ENIG
Solder Mask Apply To: TOP, Bottom
Solder Mask Color: Yellow Coverlay, Black ink
CONTOUR/CUTTING Punching
Side of Component Legend Top
Colour of Component Legend White
VIA Plated Through Hole(PTH)
FLAMIBILITY RATING UL 94-V0 Approval MIN.
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.



Dual Layer Flexible PCB Built on 1oz Polyimide With Carbon Ink and Immersion Gold For Laser Head 0

Dual Layer Flexible PCB Built on 1oz Polyimide With Carbon Ink and Immersion Gold For Laser Head 1



Bicheng Flexible Printed Circuit Capability 2019

PCB SIZE 113 x 120mm=32PCS
Base Material: Polyimide
Number of Layers Double sided FPC
SMT YES
Through Hole Components no
LAYER STACKUP Copper ------- 35um(1oz)
Adhesive
Polyimide
  Adhesive
  Copper ------- 35um(1oz)
Minimum Trace and Space: 4mil/4mil
Minimum / Maximum Holes: 0.3mm/ 2.0mm
Final foil external: 1oz
Final foil internal: 0oz
Final height of PCB: 0.15mm ±0.05
Surface Finish Immersion Gold ENIG
Solder Mask Apply To: TOP, Bottom
Solder Mask Color: Yellow Coverlay, Black ink
CONTOUR/CUTTING Punching
Side of Component Legend Top
Colour of Component Legend White
VIA Plated Through Hole(PTH)
FLAMIBILITY RATING UL 94-V0 Approval MIN.
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.
