Flexible Printed Circuit Connective Bonding Strip With Simple Design and Immersion Gold for Flexible Flat Cable

MOQ: 1PCS
Price: USD9.99-99.99
Standard Packaging: Vacuum bags+Cartons
Delivery Period: 8-9 working days
Payment Method: T/T
Supply Capacity: 5000PCS per month
Details Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
Bicheng
Certification
UL, ISO9001, IATF16949
Model Number
BIC-335.V1.0
Base Material:
Polyimide
Layer Count:
Single Side
PCB Thickness:
0.1mm ±0.05
PCB Size:
83 X 18mm=1PCS
Coverlay:
Yellow
Silkscreen:
NO
Copper Weight:
1oz
Surface Finish:
Immersion Gold
Highlight:

Simple Design Flexible Printed Circuit

Product Description



Flexible Printed Circuit Connective Bonding Strip With Simple Design and Immersion Gold for Flexible Flat Cable

(Flexible printed circuits are custom-made products, the picture and parameters shown are just for reference)



Specifications

PCB SIZE 83 x 18mm=1PCS
Base Material: Polyimide
Number of Layers Single sided PCB
SMT N/A
Through Hole Components no
LAYER STACKUP Copper ------- 35um(1oz)
Adhesive
Polyimide
Minimum Trace and Space: 10mil/15mil
Minimum / Maximum Holes: N/A
Final foil external: 1oz
Final foil internal: 0oz
Final height of PCB: 0.1mm ±0.05
Surface Finish Immersion gold
Solder Mask Apply To: TOP
Solder Mask Color: Yellow Coverlay
CONTOUR/CUTTING Punching
Stiffener: Polyimide on the back of gold finger area
Side of Component Legend NO
Colour of Component Legend NO
VIA N/A
FLAMIBILITY RATING UL 94-V0 Approval MIN.
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.



Flexible Printed Circuit Connective Bonding Strip With Simple Design and Immersion Gold for Flexible Flat Cable 0Flexible Printed Circuit Connective Bonding Strip With Simple Design and Immersion Gold for Flexible Flat Cable 1Flexible Printed Circuit Connective Bonding Strip With Simple Design and Immersion Gold for Flexible Flat Cable 2



Bicheng Flexible Printed Circuit Capability 2020
No. Specifications Capabilities
1 Board Type Single layer, Doulbe layer, Multilayer, Rigid-Flex
2 Base Material PI, PET
3 Copper Weight 0.5oz, 1oz, 2oz
4 LED Maximum Size 250 x 5000mm
5 General Maximum Size 250 x 2000mm
6 Board Thickness 0.03mm-3.0mm
7 Thickness Tolerance ±0.03mm
8 Mininum Drill Hole 0.05mm
9 Maximum Drill Hole 6.5mm
10 Tolerance of Drill Hole ±0.025mm
11 Thickness of Hole Wall ≧ 8 um
12 Minimum Track/Gap of Single Layer Board 0.025/0.03mm
13 Minimum Track/Gap of Double Layer and Multilayer Board 0.03/0.040mm
14 Etching Tolerance ±0.02mm
15 Minimum Width of Silk Legend ≧ 0.125mm
16 Minimum Heigh of Silk Legend ≧0.75mm
17 Distance from Legend to Pad ≧0.15mm
18 Distance from Opening Solder Mask of Drill Coverlay to Track ≧0.03mm
19 Distance from Opening Solder Mask of Punching Coverlay to Track ≧0.03mm
20 Thickness of Immersion Nickel 100-300u"
21 Thickness of Immersion Gold 1-3u"
22 Thicnkess of Immersion Tin 150-400u"
23 Minimum Electrical Testing Pad 0.2mm
24 Minimum Tolerance of Outline(Normal Steel Mould Punch) ±0.1mm
25 Minimum Tolerance of Outline (Precision Steel Mould Punch) ±0.05mm
26 Mininum Radius of Bevel Angle (Outline) 0.2mm
27 Stiffner Material PI, FR-4, 3M Adhesive, PET, Steel Sheet
28 RoHs Yes
29 Solder Mask Colour Yellow, White, Black, Green



Flexible Printed Circuit Connective Bonding Strip With Simple Design and Immersion Gold for Flexible Flat Cable 3Flexible Printed Circuit Connective Bonding Strip With Simple Design and Immersion Gold for Flexible Flat Cable 4

Flexible Printed Circuit Connective Bonding Strip With Simple Design and Immersion Gold for Flexible Flat Cable 5
