White Flexible PCB Board on PET with Bulge Pads and Immersion Gold for Printer
  • name
  • name
  • name
  • name
  • name
  • name

White Flexible PCB Board on PET with Bulge Pads and Immersion Gold for Printer

MOQ: 1PCS
Price: USD9.99-99.99
Standard Packaging: Vacuum bags+Cartons
Delivery Period: 8-9 working days
Payment Method: T/T
Supply Capacity: 5000PCS per month
Details Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
Bicheng
Certification
UL, ISO9001, IATF16949
Model Number
BIC-334.V1.0
Base Material:
PET
Layer Count:
2 Layers
PCB Thickness:
0.25±0.05
PCB Size:
172 X 145mm=1PCS
Coverlay:
White
Silkscreen:
NO
Copper Weight:
1oz
Surface Finish:
Immersion Gold
Highlight:

PET Flexible PCB Board

,

Immersion Gold Flexible PCB Board

,

White Flexible PCB Board

Product Description



White Flexible PCB Board on PET with Bulge Pads and Immersion Gold for Printer

(Flexible printed circuits are custom-made products, the picture and parameters shown are just for reference)



Specifications

PCB SIZE 172 x 145mm=1PCS
Base Material: PET
Number of Layers Double sided PCB
SMT n/a
Through Hole Components no
LAYER STACKUP Copper ------- 35um(1oz)
Adhesive
PET
Adhesive
Copper ------- 35um(1oz)
Minimum Trace and Space: 4mil/8mil
Minimum / Maximum Holes: 1.2mm/ 3.5mm
Final foil external: 1oz
Final foil internal: 0oz
Final height of PCB: 0.25mm ±0.05
Surface Finish Immersion gold
Solder Mask Apply To: TOP, Bottom
Solder Mask Color: White Coverlay
CONTOUR/CUTTING Punching
Stiffener: PET on back of gold finger area
Side of Component Legend NO
Colour of Component Legend NO
VIA Plated Through Hole(PTH)
FLAMIBILITY RATING UL 94-V0 Approval MIN.
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.



White Flexible PCB Board on PET with Bulge Pads and Immersion Gold for Printer 0White Flexible PCB Board on PET with Bulge Pads and Immersion Gold for Printer 1White Flexible PCB Board on PET with Bulge Pads and Immersion Gold for Printer 2



Bicheng Flexible Printed Circuit Capability 2019
No. Specifications Capabilities
1 Board Type Single layer, Doulbe layer, Multilayer, Rigid-Flex
2 Base Material PI, PET
3 Copper Weight 0.5oz, 1oz, 2oz
4 LED Maximum Size 250 x 5000mm
5 General Maximum Size 250 x 2000mm
6 Board Thickness 0.03mm-3.0mm
7 Thickness Tolerance ±0.03mm
8 Mininum Drill Hole 0.05mm
9 Maximum Drill Hole 6.5mm
10 Tolerance of Drill Hole ±0.025mm
11 Thickness of Hole Wall ≧ 8 um
12 Minimum Track/Gap of Single Layer Board 0.025/0.03mm
13 Minimum Track/Gap of Double Layer and Multilayer Board 0.03/0.040mm
14 Etching Tolerance ±0.02mm
15 Minimum Width of Silk Legend ≧ 0.125mm
16 Minimum Heigh of Silk Legend ≧0.75mm
17 Distance from Legend to Pad ≧0.15mm
18 Distance from Opening Solder Mask of Drill Coverlay to Track ≧0.03mm
19 Distance from Opening Solder Mask of Punching Coverlay to Track ≧0.03mm
20 Thickness of Immersion Nickel 100-300u"
21 Thickness of Immersion Gold 1-3u"
22 Thicnkess of Immersion Tin 150-400u"
23 Minimum Electrical Testing Pad 0.2mm
24 Minimum Tolerance of Outline(Normal Steel Mould Punch) ±0.1mm
25 Minimum Tolerance of Outline (Precision Steel Mould Punch) ±0.05mm
26 Mininum Radius of Bevel Angle (Outline) 0.2mm
27 Stiffner Material PI, FR-4, 3M Adhesive, PET, Steel Sheet
28 RoHs Yes
29 Solder Mask Colour Yellow, White, Black, Green



White Flexible PCB Board on PET with Bulge Pads and Immersion Gold for Printer 3
