2-layer F4BTMS265 PCB 30mil High-Frequency Substrate

2-layer F4BTMS265 PCB 30mil High-Frequency Substrate

MOQ: 1PCS
Price: USD9.99-99.99
Standard Packaging: Vacuum bags+Cartons
Delivery Period: 8-9 working days
Payment Method: T/T
Supply Capacity: 5000PCS per month
Detail Information
Place of Origin
CHINA
Brand Name
Bicheng
Certification
UL, ISO9001, IATF16949
Model Number
BIC-268.V1.0
Base Material:
F4BTMS265
Layer Count:
2 Layers
PCB Thickness:
0.85mm
PCB Size:
97mm × 76mm (1 Piece), Dimensional Tolerance: ±0.15mm
Solder Mask:
Black
Silkscreen:
White
Copper Weight:
1oz (1.4 Mils) Outer Copper Layer
Surface Finish:
ENIG (Electroless Nickel Immersion Gold)
Highlight:

Polyimide Stiffener 4 Layer Flex PCB

,

2 Oz Copper 4 Layer Flex PCB

,

Polyimide Stiffener 2 Oz Copper PCB

Product Description

This 2-layer rigid high-frequency PCB features aerospace-grade F4BTMS265 ceramic-filled dielectric substrate with low electromagnetic loss and minimal anisotropy. It adopts ENIG surface treatment, black top solder mask and white top silkscreen, with a fully mask-free and silkscreen-free bottom side. All units pass 100% electrical testing before delivery, ensuring stable dielectric performance, low signal attenuation and reliable structure for aerospace, military and RF/microwave applications.



PCB Specifications

Parameter Item Specification
Base Material F4BTMS265 upgraded ceramic-filled high-frequency substrate
Layer Configuration 2-layer rigid PCB structure
Board Dimension 97mm × 76mm (1 piece), dimensional tolerance: ±0.15mm
Minimum Trace / Space 14 mils / 14 mils
Minimum Mechanical Hole Diameter 0.25mm
Via Type Pure through-hole vias, no blind vias
Finished Board Thickness 0.85mm
Outer Copper Weight 1oz (1.4 mils) outer copper layer
Via Plating Thickness 20μm
Surface Finishing ENIG (Electroless Nickel Immersion Gold)
Top Silkscreen White silkscreen
Bottom Silkscreen Silkscreen-free
Top Solder Mask Black solder mask
Bottom Solder Mask Solder mask-free
Quality Inspection 100% full electrical testing performed prior to delivery



PCB Layer Stack-up Structure

Layer Definition Technical Specification
Top Copper Layer 35μm finished copper thickness
Dielectric Core Substrate F4BTMS265 core, 0.762mm (30mil) thickness
Bottom Copper Layer 35μm finished copper thickness
