We are excited to introduce our newly shipped PCB featuring Rogers CuClad 250 laminates, a cutting-edge solution designed for high-performance applications in the electronics industry. This 2-layer rigid PCB combines advanced materials and meticulous construction to deliver exceptional electrical and mechanical properties, making it ideal for a range of demanding environments.
Key Features of Rogers CuClad 250
- Dielectric Constant: Ranges from 2.40 to 2.55 at 10GHz, providing superior performance for high-frequency applications.
- Dissipation Factor: An impressive 0.0017 at 10GHz, ensuring low circuit losses.
- Low Moisture Absorption: Just 0.03%, enhancing reliability in various conditions.
- Strong Peel Strength: 14 lbs/in, ensuring durability and stability.
- Low Outgassing: Total Mass Loss (TML) of 0.01% and no Water Vapor Regain (WVR), ideal for sensitive applications.
- Cross-Ply Construction: Woven fiberglass with alternating plies oriented at 90 degrees, providing balanced mechanical and electrical properties.
- High PTFE to Glass Ratio: Enhances dimensional stability and thermal performance.
Benefits of CuClad 250
The cross-plied construction of Rogers CuClad 250 results in balanced electrical and mechanical characteristics, making it particularly well-suited for:
- Wider Line Widths: Supports lower insertion loss, crucial for high-frequency performance.
- Low Circuit Losses: Ideal for applications requiring reliable signal integrity.
- Dielectric Constant Uniformity: Offers better consistency compared to traditional non-woven fiberglass reinforced laminates, ensuring optimal performance in Er-sensitive circuits.
PCB Stack-Up and Construction Details
This 2-layer rigid PCB features:
- Copper Layer 1: 35 μm
- Rogers CuClad 250 Core: 0.508 mm (20 mil)
- Copper Layer 2: 35 μm
The dimensions of the newly shipped PCB are specified as 23.97 mm x 30.09 mm, allowing for a tolerance of ± 0.15 mm to ensure precise fit and compatibility with various applications. A finished board thickness of 0.6 mm is provided, offering a robust structure while maintaining a lightweight profile.
For surface finish, ENIG (Electroless Nickel Immersion Gold) is utilized, providing excellent solderability and corrosion resistance. The top silkscreen is printed in white for clarity in component identification, while a vibrant blue color is used for the top solder mask, offering both protection and aesthetic appeal.
To ensure quality assurance, a 100% electrical test is conducted prior to shipment, guaranteeing that every PCB meets rigorous performance standards. This commitment to quality is intended to ensure reliability and functionality in diverse applications.
The artwork is supplied in the Gerber RS-274-X format, ensuring compatibility with industry-standard fabrication processes.
Quality Assurance
Manufactured in accordance with IPC-Class-2 standards, this PCB guarantees a moderate level of reliability suitable for consumer electronics and beyond. This commitment to quality ensures that you receive a product that meets the highest performance benchmarks.
Typical Applications
The Rogers CuClad 250 PCB is perfect for a variety of applications, including:
- Radars: High-performance radar systems requiring precision and reliability.
- Electronic Countermeasures: Effective for advanced defense applications.
- Microwave Components: Ideal for Low Noise Amplifiers (LNAs), filters, couplers, and other microwave applications.
Availability
Our Rogers CuClad 250 PCB is available worldwide, ready to meet your specific project needs. Whether you're in telecommunications, aerospace, or any high-tech industry, this PCB is designed to deliver outstanding performance.
Conclusion
Discover the advantages of our newly shipped Rogers CuClad 250 PCB, engineered for excellence in high-frequency applications. With its advanced materials, robust construction, and rigorous quality standards, this PCB is your go-to solution for demanding electronic projects. Contact us today to if any inquiry for this PCB.
