Double Sided PCB On 20mil RO3010 With Green Mask White Legend Immersion Silver

As technology continues to evolve rapidly, the demand for high-performance printed circuit boards (PCBs) has never been greater. Our newly shipped double-sided PCB, constructed from Rogers RO3010 material, exemplifies cutting-edge design and exceptional reliability, making it an ideal choice for various advanced applications.

Understanding the RO3010 Material

Rogers RO3010 is a ceramic-filled PTFE composite that offers a unique combination of high dielectric constant and excellent stability. With a dielectric constant of 10.2 ± 0.30 at 10 GHz, this material is particularly suited for applications that require precise signal integrity over a broad range of frequencies. The low dissipation factor of 0.0022 at 10 GHz ensures minimal signal loss, which is crucial for high-frequency applications.

The mechanical properties of RO3010 are noteworthy as well. It exhibits a low coefficient of thermal expansion (CTE), which is critical for maintaining dimensional stability during thermal cycling. With a CTE of 13 ppm/°C in the X-direction and 11 ppm/°C in the Y-direction, the material effectively matches the expansion characteristics of copper, thereby reducing the risk of delamination and ensuring long-term reliability.

Construction Details
This PCB with the following specifications:


- Base Material: Rogers RO3010
-Layer Count: 2
- Dimensions: 60.32 mm x 59.68 mm
- Finished Board Thickness: 0.6 mm
- Copper Weight: 1 oz (1.4 mils) on outer layers
- Minimum Trace/Space: 5/6 mils
- Minimum Hole Size: 0.25 mm
- Surface Finish: Immersion Silver
- Silkscreen: White top silkscreen

PCB Stackup
The stackup consists of:


-Copper Layer 1: 35 μm
- Rogers RO3010 Substrate: 20 mil (0.508 mm)
- Copper Layer 2: 35 μm

- 100% Electrical Testing: Every board undergoes rigorous electrical testing before shipment to guarantee functionality.

Benefits of Our PCB

Exceptional Dimensional Stability
The RO3010 material provides outstanding dimensional stability, thanks to its low coefficient of thermal expansion (CTE). With CTE values of 13 ppm/°C in the X-direction and 11 ppm/°C in the Y-direction, the PCB effectively minimizes the risk of delamination and ensures reliable performance, even under thermal cycling conditions.

High Electrical Performance
Rogers RO3010 features a dielectric constant of 10.2 ± 0.30 at 10 GHz and a low dissipation factor of 0.0022, ensuring minimal signal loss and maintaining signal integrity in high-frequency applications. This makes our PCB ideal for telecommunications, automotive radar, and other demanding electronic environments.

Cost-Effective Solution
Despite its advanced performance characteristics, the PCB remains competitively priced. This economical option allows businesses to scale their production efficiently while maintaining high standards of quality.

Compliance and Quality Assurance
Manufactured to IPC-Class-2 standards, our PCB meets rigorous quality requirements. The ISO 9001 certification further demonstrates our commitment to maintaining excellence in quality management, ensuring that each board is reliable and ready for use in critical applications.

Applications
This advanced PCB is suitable for a variety of high-performance applications, including:

- Automotive Radar Systems: Enhanced performance in detecting obstacles and navigation.


- GPS Antennas: Reliable signal reception critical for accurate positioning.


- Cellular Telecommunications: Power amplifiers and antennas benefit from the low-loss characteristics.


- Wireless Communications: Patch antennas designed for robust connectivity.


- Direct Broadcast Satellites: Optimal performance in signal transmission and reception.


- Remote Meter Reading Systems: Reliable and efficient data transmission.


- Power Backplanes: Ensuring stable power distribution in complex systems.

Conclusion

Our newly shipped double-sided PCB, utilizing Rogers RO3010 material, represents a significant advancement in PCB technology. With its robust electrical performance, exceptional mechanical stability, and a wide range of applications, it stands ready to meet the evolving demands of the electronics industry. By choosing our PCB, customers can expect unparalleled quality, reliability, and performance in their electronic designs.

For more information or to place an order, please contact our sales team. We are here to assist you in finding the perfect solution for your PCB needs.
