2-layer CLTE-MW Pure Gold PCB Green Solder Mask White Legend

This custom 2-layer CLTE-MW™ rigid PCB is an ultra-thin high-frequency RF circuit board built on ceramic filled, woven glass reinforced PTFE composite substrate. With pure gold surface finish and tight dimensional tolerance, the board is constructed to a finished thickness of only 0.2mm. It uses a 0.102 mm CLTE-MW core with 35 μm copper on both layers and contains no blind vias. Manufactured to IPC-Class-2 quality standards, it undergoes 100% electrical testing before shipment. Gerber RS-274-X files are accepted for production, and worldwide delivery is available.

PCB Specifications

PCB Stack-up

PCB Statistics

CLTE-MW™ Laminate Introduction

CLTE-MW™ laminates are ceramic filled, woven glass reinforced PTFE composites, developed as a cost-effective high-performance substrate for RF designers. Suited for projects with mechanical or electrical thickness constraints, this material series offers seven standard core thicknesses from 3 mils to 10 mils, supporting optimal signal-to-ground spacing for 5G and millimeter-wave circuits. Multiple copper foil options are available, including rolled, reverse treated ED and standard ED; resistive foil and metal plate can be supplied upon request.

Spread glass reinforcement plus high filler loading reduces glass weave effects on electromagnetic wave propagation while maintaining excellent dimensional stability.

Material Features

• Low loss tangent of 0.0015 at 10GHz
• Low Z-axis CTE of 30ppm/°C
• Thermal conductivity of 0.42 W/(m·K)
• UL94 V-0 flammability rating
• Low moisture absorption of 0.03%
• High dielectric strength of 630 V/mil

Core Benefits

• Enables low loss RF circuit designs
• Excellent plated through hole (PTH) reliability
• Effective heat dissipation for demanding layouts
• Approved for commercial electronic applications
• Stable mechanical performance under thermal stress

CLTE-MW™ Standard Material Options

Typical Applications

This CLTE-MW™ 2-layer rigid PCB serves multiple high-frequency industries:

• Commercial Communications and Avionics
• Military & Aerospace Applications
• Microwave Feed Networks
• Phase Sensitive Electronic Structures
• Satellite Communication Systems
• Passive Components (couplers, filters & baluns)

Summary

This custom 2-layer CLTE-MW™ PCB combines ultra-thin construction and low-loss PTFE substrate to deliver stable RF performance. Manufactured to IPC-Class-2 standards and fully electrically tested before shipment, the pure gold finished board is a trusted solution for millimeter-wave, satellite and aerospace electronics, available for global customers.
