In the ever-evolving world of electronics, reliability and performance are non-negotiable. We are proud to introduce our advanced 2-layer PCB, crafted with TU-865 material, a halogen-free, high-performance laminate designed to excel in the most demanding environments. This PCB is engineered to deliver exceptional electrical performance, thermal stability, and environmental resilience, making it the ideal choice for a wide range of applications.
Product Overview
Our 2-layer PCB is built to meet the highest standards of quality and reliability. Here are the key specifications:
Board Type: 2-layer rigid PCB
Material: TU-865 (halogen-free, high Tg)
Solder Mask: Both sides, green
Silkscreen Print: Top side, white
Surface Finish: ENIG (Electroless Nickel Immersion Gold)
Board Thickness: 3.0mm ±10%
Board Size: 120mm x 210mm (1 piece per panel)
Minimum Hole Size: 0.4mm
Solder Mask Thickness: 100μm
Trace Width/Spacing: 600μm (minimum)
PCB Stack-Up
The stack-up of this PCB is meticulously designed to ensure optimal performance:
Top Layer: 350μm copper
Core: TU-865, 3000μm (compliant with IPC-4101/24)
Bottom Layer: 350μm copper
This robust structure ensures excellent signal integrity, thermal management, and mechanical stability.
Why TU-865 Material?
TU-865 is a game-changer in PCB materials, offering a unique combination of high reliability and superior electrical performance. Here’s what makes it stand out:
High Glass Transition Temperature (Tg): 200°C (DSC) and 185°C (TMA), ensuring stability under high temperatures.
Low Dielectric Constant: 4.4 @ 10GHz, minimizing signal loss and enhancing signal integrity.
Low Dissipation Factor: 0.014 @ 10GHz, reducing energy loss in high-frequency applications.
Moisture Resistance: 0.13%, ensuring reliability in humid environments.
Lead-Free Processing Compatibility: Meets modern manufacturing requirements.
Anti-CAF Capability: Prevents conductive anodic filament formation, enhancing long-term reliability.
Environmental Friendly: Halogen-free, aligning with global environmental standards.
Key Features of this PCB
Exceptional Thermal Stability: Withstands severe thermal cycling, making it ideal for high-temperature applications.
Superior Electrical Performance: Low dielectric constant and dissipation factor ensure minimal signal loss.
Robust Mechanical Properties: Excellent dimensional stability and moisture resistance for reliable performance in harsh conditions.
Environmental Compliance: Halogen-free material supports eco-friendly manufacturing processes.
High Reliability: Anti-CAF capability and lead-free compatibility ensure long-term durability.
Applications
This PCB is designed for industries that demand high reliability and performance under challenging conditions:
Automotive: Ideal for engine control units, sensors, and infotainment systems that require durability and thermal stability.
Telecom and Base Stations: Ensures stable signal transmission and reliability in high-frequency applications.
Servers and Data Centers: Delivers consistent performance under high workloads and thermal stress.
Industrial Electronics: Suitable for harsh environments, including factory automation and power electronics.
Global Availability
Our 2-layer PCB with TU-865 material is available worldwide, ensuring that you can access high-quality, reliable PCBs no matter where your operations are located.
Why Choose Us?
Uncompromising Quality: Compliant with IPC-Class-2 standards, ensuring reliability and performance.
Advanced Materials: TU-865 provides exceptional thermal, electrical, and environmental properties.
Custom Solutions: Tailored to meet your specific design and application requirements.
Global Support: Reliable delivery and technical assistance worldwide.
Conclusion
Our 2-layer PCB with TU-865 material is the perfect solution for industries that require high reliability, superior performance, and environmental compliance. Whether you’re developing automotive systems, telecom infrastructure, or industrial electronics, this PCB delivers the durability and performance you need to succeed.
Contact us today to learn more or request a quote! Let’s work together to bring your innovative designs to life.
