Multilayer PCB 2mm FR408HR Via Filled And Capped Immersion Gold

Multilayer PCB 2mm FR408HR Via Filled And Capped Immersion Gold
Multilayer PCB 2mm FR408HR Via Filled And Capped Immersion Gold

Large Image :  Multilayer PCB 2mm FR408HR Via Filled And Capped Immersion Gold

Product Details:
Place of Origin: CHINA
Brand Name: Bicheng
Certification: UL, ISO9001, IATF16949
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD9.99-99.99/PCS
Packaging Details: Vacuum bags+Cartons
Delivery Time: 8-9 working days
Payment Terms: T/T
Supply Ability: 5000PCS per month
Detailed Product Description
Material: FR4 PCB Size: 170mm X 130mm (1PCS)
Copper Weight: 35um Surface Finish: Immersion Gold
High Light:

Immersion Gold Multilayer PCB


Capped Immersion Gold Multilayer PCB


Capped Multilayer PCB

Introducing our high-performance Multilayer PCB built on FR408HR.This Multilayer PCB is designed for applications that demand maximum thermal performance and reliability. Crafted using Isola's patented high-performance multifunctional resin system, reinforced with electrical grade (E-glass) glass fabric, this PCB offers exceptional properties that bridge the gap between thermal and electrical perspectives.


Key Features:
- Dielectric Constant (Dk): Boasting a Dk of 3.65 at 10GHz, this PCB ensures excellent signal integrity and reliable performance in high-frequency applications.


- Dissipation Factor: With a dissipation factor of 0.0095 at 10GHz, it minimizes signal loss, providing efficient power transmission.

- Coefficient of Thermal Expansion (CTE): The CTE of 16 ppm/°C in both the x and y axes ensures compatibility with copper, reducing thermal stress and enhancing reliability.

- Thermal Stability: Featuring a high glass transition temperature (Tg) of 230°C (DMA) and a decomposition temperature (Td) of 360°C (TGA), this PCB exhibits exceptional thermal stability.

- Multiple Lamination Cycles: It can withstand multiple lamination cycles, providing flexibility in the PCB manufacturing process.

- Lead-Free Assembly Compatibility: Designed to be compatible with lead-free assembly processes, ensuring compliance with modern industry standards.

- Via Filling Capability: This PCB supports via filling, enhancing electrical connectivity and improving signal integrity.

- CAF Resistance: With superior resistance to Conductive Anodic Filament (CAF) formation, it ensures long-term reliability and performance.

- Moisture Resistance: The FR408HR exhibits superior moisture resistance during reflow, safeguarding against environmental factors.


Multilayer PCB 2mm FR408HR Via Filled And Capped Immersion Gold 0


PCB Stackup:
This PCB is a 4-layer rigid PCB with the following stackup:
- Top Layer: 35 μm copper
- Prepreg: 152 μm
- Inner Layer 1: 35 μm copper
- FR408HR Core: 1.535 mm
- Inner Layer 2: 35 μm copper
- Prepreg: 152 μm
- Bottom Layer: 35 μm copper


PCB Construction Details:
- Dimensions: 170mm x 130mm (1PCS), with a tolerance of +/- 0.15mm
- Minimum Trace/Space: 4/5 mils, enabling precise circuit design and layout
- Minimum Hole Size: 0.3mm, supporting fine-pitch components and high-density interconnects
- Blind Vias: Allowing for complex routing and efficient use of available space
- Finished Board Thickness: 2.0mm, providing structural integrity and durability
- Finished Copper Weight: 1oz (1.4 mils) on outer layers, ensuring optimal conductivity
- Via Plating Thickness: 20 μm, facilitating reliable electrical connections
- Surface Finish: Immersion Gold, offering excellent solderability and corrosion resistance
- Silkscreen: Top layer in white, providing component and labeling information
- Solder Mask: Red on both top and bottom layers, protecting copper traces and preventing solder bridges
- Filled and Capped Vias: Enhancing signal integrity and improving overall PCB performance
- 100% Electrical Test: Each PCB undergoes a comprehensive electrical test prior to shipment, ensuring functionality and quality.


Multilayer PCB 2mm FR408HR Via Filled And Capped Immersion Gold 1


PCB Statistics:
- Components: 270
- Total Pads: 320
- Thru Hole Pads: 150
- Top SMT Pads: 99
- Bottom SMT Pads: 71
- Vias: 78
- Nets: 6


Quality Standard and Availability:

- Quality Standard: This Multilayer PCB complies with IPC-Class-2 quality standards, ensuring high reliability and performance.

- Availability: This high-performance PCB is available worldwide, meeting the needs of diverse industries and applications.


Typical Applications:
This Multilayer PCB finds its application in various industries, including:


- Consumer Electronics: From smartphones to audio/video equipment, this PCB supports the demanding requirements of modern consumer electronic devices.

- Server and Workstation: It provides the necessary performance and reliability for high-end server and workstation applications.

- Automotive: The FR408HR PCB is suitable for automotive electronics, offering robustness and thermal stability in challenging automotive environments.
