1.2mm T110 8OZ Aluminum PCB 1-layer OSP finished Heavy Copper

1.2mm T110 8OZ Aluminum PCB 1-layer OSP finished Heavy Copper
1.2mm T110 8OZ Aluminum PCB 1-layer OSP finished Heavy Copper 1.2mm T110 8OZ Aluminum PCB 1-layer OSP finished Heavy Copper 1.2mm T110 8OZ Aluminum PCB 1-layer OSP finished Heavy Copper 1.2mm T110 8OZ Aluminum PCB 1-layer OSP finished Heavy Copper

Large Image :  1.2mm T110 8OZ Aluminum PCB 1-layer OSP finished Heavy Copper

Product Details:
Place of Origin: CHINA
Brand Name: Bicheng
Certification: UL, ISO9001, IATF16949
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD9.99-99.99
Packaging Details: Vacuum bags+Cartons
Delivery Time: 8-9 working days
Payment Terms: T/T
Supply Ability: 5000PCS per month
Detailed Product Description
Material: Aluminum Thickness: 1.2mm
Surface Finish: OSP Copper Weight: 8 OZ

Introducing our latest PCB shipment, featuring the cutting-edge T110 series from Totking. This exceptional PCB offers a host of remarkable features and benefits that will revolutionize your electronic designs. Let's dive into the details and explore why the T110 series is the perfect choice for your projects.



T110 Series Unveiled:
Totking's T110 series comprises a range of metal substrates, including aluminum, ferrum, copper, and stainless steel. With options like aluminum substrates (1100, 3003, 5052, and 6061), ferrum (SECC), copper (1100), and stainless steel (SUS304 and SUS316), you have the flexibility to choose the ideal material for your needs. These substrates offer excellent thermal conductivity, ranging from 1.0W/mk to 2.0W/mk, while the copper weight options span from 0.5oz to 10oz.



Unparalleled Features:
- Experience the remarkable peel strength of 1.8 N/mm, ensuring the longevity and stability of your PCB.
- Withstanding thermal stress for 90 seconds without delamination or bubble formation showcases the exceptional durability of the T110 series.
- Achieve optimal performance with a surface resistivity of 10^7 Mohm and a volume resistivity of 10^7 Mohm-cm, guaranteeing excellent electrical properties.
- The impressive electrical strength of 30 KV/mm ensures reliable and efficient functionality.
- A high glass transition temperature (Tg) of 100℃ provides enhanced stability and durability in demanding conditions.
- The T110 series boasts a V-0 flammability rating, meeting the stringent UL94 standards for fire safety.
- With a water absorption rate of just 0.03%, the T110 series exhibits excellent resistance to moisture.
- The Comparative Tracking Index (CTI) of 600V ensures reliable performance in varying environments.



1.2mm T110 8OZ Aluminum PCB 1-layer OSP finished Heavy Copper 0



Unmatched Benefits:
- Enjoy superior heat dissipation capabilities, ensuring optimal performance and reliability in high-temperature applications.
- The T110 series provides excellent insulation properties, guaranteeing the safety and efficiency of your electronic circuits.
- Benefit from exceptional dimensional stability, ensuring the integrity of your designs even under challenging conditions.
- The T110 series offers outstanding machinability, allowing for effortless processing and customization.
- Shielding your circuits from electromagnetic waves becomes effortless with the T110 series.
- Experience exceptional cost-effectiveness, as the T110 series delivers outstanding performance without compromising your budget.



PCB Specifications:
This PCB features a 1-layer rigid design with the following stackup:
- Copper Layer 1: 280 μm (8oz).
- Dielectric layer.
- Aluminum Base: 1.0 mm.



Additional Details:
- The board dimensions measure 80mm x 52mm (1PCS), with a tolerance of +/- 0.15mm.
- Achieve precise designs with a minimum trace/space of 15/20 mils.
- The minimum hole size is 1.0mm, ensuring compatibility with various components.
- The finished board thickness stands at 1.2mm, striking the perfect balance between durability and flexibility.
- The outer layers feature a finished copper weight of 8oz (11.2 mils), ensuring optimal conductivity.
- The surface finish is OSP, providing excellent solderability and corrosion resistance.
- The absence of top and bottom silkscreen and solder mask allows for a clean and minimalist appearance.
- Rest assured, each PCB undergoes a comprehensive 100% electrical test before shipment, ensuring its reliability.



Additional Information:
- The T110 series adheres to the IPC-Class-2 quality standard, guaranteeing top-notch performance and reliability.
- With worldwide availability, you can access the T110 series no matter where your projects take you.



Applications:
The T110 series PCB finds its application in a wide range of scenarios, including:
- Illuminating your designs with LED lighting circuits.
- Nurturing innovation with thick-film hybrid integrated circuits.
- Empowering your power circuits with superior performance.
- Achieving seamless functionality with solid-state relays.



Discover a new realm of excellence, reliability, and adaptability with the T110 series PCB from Totking. Elevate your electronic designs with unwavering confidence, as this cutting-edge PCB seamlessly integrates advanced features, unmatched advantages, and global availability. Embrace the transformative power of the T110 series to revolutionize your projects and ensure their resounding success.
