Rogers 4350 Dual Layer 6.6 Mil High Frequency PCB With Immersion Gold

Rogers 4350 Dual Layer 6.6 Mil High Frequency PCB With Immersion Gold
Rogers 4350 Dual Layer 6.6 Mil High Frequency PCB With Immersion Gold

Large Image :  Rogers 4350 Dual Layer 6.6 Mil High Frequency PCB With Immersion Gold

Product Details:
Place of Origin: CHINA
Brand Name: Bicheng
Certification: UL, ISO9001, IATF16949
Model Number: BIC-2.V1.0
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD9.99-99.99
Packaging Details: Vacuum bags+Cartons
Delivery Time: 8-9 working days
Payment Terms: T/T
Supply Ability: 5000PCS per month
Detailed Product Description
Based Material: Rogers 4350 PCB Thickness: 6.6 Mil
PCB Size: ≤400mm X 500mm Surface: Gold
High Light:

Dual Layer High Frequency PCB

,

6.6 Mil High Frequency PCB

,

Immersion Gold Two Layer Pcb

Rogers 4350 Dual layer 6.6 mil High frequency PCB with Immersion Gold



The qualities required by designers of RF microwave circuits, matching networks, and controlled impedance transmission lines are present in the material RO4350B. Since standard circuit board materials cannot be used in many applications due to higher operating frequencies, low dielectric loss makes it possible to employ RO4350B material in these applications.



The dielectric constant is consistent across a wide frequency range and has one of the lowest temperature coefficients of any circuit board material.



Main applications:

Low Noise Block

Power amplifiers

RFID



RO4350B Typical Value
Property RO4350B Direction Units Condition Test Method
Dielectric Constant,εProcess 3.48±0.05 Z   10 GHz/23℃ IPC-TM-650 2.5.5.5 Clamped Stripline
Dielectric Constant,εDesign 3.66 Z   8 to 40 GHz Differential Phase Length Method
Dissipation Factortan,δ 0.0037
0.0031
Z   10 GHz/23℃
2.5 GHz/23℃
IPC-TM-650 2.5.5.5
Thermal Coefficient of ε +50 Z ppm/℃ -50℃to 150℃ IPC-TM-650 2.5.5.5
Volume Resistivity 1.2 x 1010   MΩ.cm COND A IPC-TM-650 2.5.17.1
Surface Resistivity 5.7 x109   COND A IPC-TM-650 2.5.17.1
Electrical Strength 31.2(780) Z Kv/mm(v/mil) 0.51mm(0.020") IPC-TM-650 2.5.6.2
Tensile Modulus 16,767(2,432)
14,153(2,053)
X
Y
MPa(ksi) RT ASTM D 638
Tensile Strength 203(29.5)
130(18.9)
X
Y
MPa(ksi) RT ASTM D 638
Flexural Strength 255
(37)
  MPa
(kpsi)
  IPC-TM-650 2.4.4
Dimensional Stability <0.5 X,Y mm/m
(mil/inch)
after etch+E2/150℃ IPC-TM-650 2.4.39A
Coefficient of Thermal Expansion 10
12
32
X
Y
Z
ppm/℃ -55℃to288℃ IPC-TM-650 2.4.41
Tg >280   ℃ TMA A IPC-TM-650 2.4.24.3
Td 390   ℃ TGA   ASTM D 3850
Thermal Conductivity 0.69   W/M/oK 80℃ ASTM C518
Moisture Absorption 0.06   % 48hrs immersion 0.060"
sample Temperature 50℃
ASTM D 570
Density 1.86   gm/cm3 23℃ ASTM D 792
Copper Peel Stength 0.88
(5.0)
  N/mm
(pli)
after solder float 1 oz.
EDC Foil
IPC-TM-650 2.4.8
Flammability (3)V-0       UL 94
Lead-free Process Compatible Yes
