Customize UL Printed Circuit Board Signal Integrity Improved
  • name
  • name
  • name

Customize UL Printed Circuit Board Signal Integrity Improved

MOQ: 1PCS
Price: USD9.99-99.99
Standard Packaging: Vacuum bags+Cartons
Delivery Period: 8-9 working days
Payment Method: T/T
Supply Capacity: 5000PCS per month
Details Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
Bicheng
Certification
UL, ISO9001, IATF16949
Model Number
BIC-206.V1.0
Copper Thickness:
1oz
Application:
Electronics Device,Consumer Electronics,Communications,and So On
Solder Mask Color:
Green
Product Name:
Printed Circuit Board
Silkscreen Color:
White
Service:
Customize
Highlight:

1oz Printed Circuit Board

,

Customize UL Printed Circuit Board

Product Description



How to specify a PCB?



A PCB user generally needs to present all of the primary manufacturing data in a complete and unambiguous way that the PCB manufacturer can quote and produce the boards without error.



A checklist is listed as follows. Some parameters not necessary for a particular job can be deleted so that the specification form only reflects the relevant data.



(1)Company name

(2)Part number

(3)Lot size and annual requirements

(4)Layer count

(5)Board size

(6)Board thickness

(7)Board shape

(8)Panelization

(9)Board build-up

(10)Boards with controlled impedance

(11)Test coupon

(12)Machining (Contouring)

(13)Laminate type and UL flammability

(14)Warp & Twist

(15)Outer layers

(16)Inner layers

(17)Solderability preservation

(18)Solder masks

(19)Notation

(20)Peelable solder mask

(21)Carbon printing

(22)Plated through holes (PTHs)

(23)Non-PTHs

(24)Milled Holes (Slots)

(25) Blind via holes

(26) Buried via holes

(27)Board tooling holes

(28)Panel tooling holes

(29)Board mounting

(30)Edge connectors

(31)Soldering conditions

(32)Markings

(33)Electrical test

(34)Automatic optical inspection

(35)Minimum pattern conditions

(36)Quality conditions



A view of PCB panelization

Customize UL Printed Circuit Board Signal Integrity Improved 0



Customize UL Printed Circuit Board Signal Integrity Improved 1



To know a basic situation of one PCB, these 7 points have to be taken into consideration:

(1) Laminate type (base material)

(2) Layer count

(3) Board size

(4) Board thickness

(5) Copper weight

(6) The color of solder mask and silkscreen

(7) Surface finish



Is it much simple now?

If you have any enquiries, please feel free to contact us. Welcome your patronage.
