RO4003C and RO4450F high frequency Radar Altimeter HDI PCB Board 1.94mm 6 Layer PCB

RO4003C and RO4450F high frequency Radar Altimeter HDI PCB Board 1.94mm 6 Layer PCB
RO4003C and RO4450F high frequency Radar Altimeter HDI PCB Board 1.94mm 6 Layer PCB RO4003C and RO4450F high frequency Radar Altimeter HDI PCB Board 1.94mm 6 Layer PCB RO4003C and RO4450F high frequency Radar Altimeter HDI PCB Board 1.94mm 6 Layer PCB RO4003C and RO4450F high frequency Radar Altimeter HDI PCB Board 1.94mm 6 Layer PCB

Large Image :  RO4003C and RO4450F high frequency Radar Altimeter HDI PCB Board 1.94mm 6 Layer PCB

Product Details:
Place of Origin: CHINA
Brand Name: Bicheng
Certification: UL, ISO9001, IATF16949
Model Number: BIC-070.V1.0
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD9.99-99.99
Packaging Details: Vacuum bags+Cartons
Delivery Time: 8-9 working days
Payment Terms: T/T
Supply Ability: 5000PCS per month
Detailed Product Description
Base Material: RO4003C 0.508 Mm X 3 Sheets, RO4450F 0.102mm X 1 Sheet Layer Count: 6 Layers
PCB Thickness: 1.94mm PCB Size: 129mm X 75mm = 1 Type = 1 Piece
Solder Mask: Green Silkscreen: White
Copper Weight: 1oz Surface Finish: Immersion Gold
High Light:

1.94mm HDI PCB Board

,

Radar Altimeter HDI PCB Board

,

1.94mm 6 Layer PCB



6 Layer High Frequency PCB Built On 3 Cores of 20mil RO4003C and 4mil RO4450F for Radar Altimeter

(Printed circuit boards are custom-made products, the picture and parameters shown are just for reference)



Today we talked about is a type of 6 layers high frequency PCB. It’s built on 3 core of 20mil RO4003C with bondply RO4450F for the application of radar altimeter. The stack-up is as follows.



RO4003C and RO4450F high frequency Radar Altimeter HDI PCB Board 1.94mm 6 Layer PCB 0



As is known to all, there’re 6 cores in RO4003C family, i.e. 8mil (0.203mm) to 60mil (1.524mm).



RO4003C:
8mil 0.203mm
12mil 0.305mm
16mil 0.406mm
20mil 0.508mm
32mil 0.813mm
60mil 1.524mm



So it’s very interesting that stack-up of 4 layers can be done in many different ways.



Following is the basic specifications.

Base material: RO4003C 0.508 mm x 3 sheets, RO4450F 0.102mm x 1 sheet

Layer count: 6 layers

Type: 1 PCB up per panel with v-cut

Format: 129mm x 75mm = 1 type = 1 piece

Surface finish: Immersion gold

Copper weight: Outer layer 35 μm/ Inner layer 35 μm

Solder mask / Legend: Green / White

Final PCB height: 1.94 mm

Standard: IPC 6012 Class 2

Packing: 20 panels are packed for shipment.

Lead time: 10 working days

Shelf life: 6 months



Features and benefits

1) RO4003C exhibits a stable dielectric constant over a broad frequency range. This makes it an ideal substrate for broadband applications;

2) Reducing signal loss in high frequency application meets the development needs of communication technology;

3) UL, ISO14001, IATF16949 certified factory;

4) 16000 square meter workshop;

5) More than 17 years of PCB experience;



Applications

Satellite antenna, Power splitter, Radio frequency, Power divider



PCB Data Sheet

PCB SIZE 129 x 75mm=1PCS
BOARD TYPE Multilayer PCB
Number of Layers 6 layers
Surface Mount Components YES
Through Hole Components YES
LAYER STACKUP copper --------35µm (1 oz)+plate TOP layer
RO4003C 0.508mm
copper ------- 35µm(1 oz)
  Prepreg RO4450F 0.101mm
  Copper ------- 35µm (1 oz)
  RO4003C 0.508mm
  Copper ------- 35µm (1 oz)
  Prepreg RO4450F 0.101mm
  Copper ------- 35µm (1 oz)
  RO4003C 0.508mm
  copper --------35µm (1 oz)+plate BOT layer
TECHNOLOGY
Minimum Trace and Space: 6mil / 6 mil
Minimum / Maximum Holes: 0.4 mm / 3.5 mm
Number of Different Holes: 15
Number of Drill Holes: 324
Number of Milled Slots: 0
Number of Internal Cutouts: 0
Impedance Control: no
Number of Gold finger: 0
BOARD MATERIAL
Glass Epoxy: RO4003C, RO4450F, Tg280℃, er<3.48, Rogers Corp.
Final foil external: 1 oz
Final foil internal: 1 oz
Final height of PCB: 1.94 mm ±10%
PLATING AND COATING
Surface Finish Immersion gold 0.05 micron over nickle 4.4 micron
Solder Mask Apply To: N/A
Solder Mask Color: N/A
Solder Mask Type: N/A
CONTOUR/CUTTING Routing
MARKING
Side of Component Legend N/A
Colour of Component Legend N/A
Manufacturer Name or Logo: N/A
VIA Plated through hole(PTH), minimum size 0.4mm. No blind via or buried vias
FLAMIBILITY RATING UL 94-V0 Approval MIN.
DIMENSION TOLERANCE
Outline dimension: 0.0059"
Board plating: 0.0029"
Drill tolerance: 0.002"
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.
