F4BTME298 Rf Circuit Board 60mil 2-Layer Immersion Tin

F4BTME298 Rf Circuit Board 60mil 2-Layer Immersion Tin

MOQ: 1PCS
Price: USD9.99-99.99/PCS
Standard Packaging: Vacuum bags+Cartons
Delivery Period: 8-9 working days
Payment Method: T/T
Supply Capacity: 5000PCS per month
Detail Information
Place of Origin
CHINA
Brand Name
Bicheng
Certification
UL, ISO9001, IATF16949
Material:
F4BTME298 Core
PCB Size:
51.51mm X 111.92 Mm=1PCS, +/- 0.15mm
Copper Weight:
1oz (1.4 Mils) Outer Layers
Surface Finish:
Immersion Tin
Layer Count:
2-layer
PCB Thickness:
1.6mm
Highlight:

F4BTME298 rf circuit board

,

60mil rf circuit board

,

Immersion Tin rf board

Product Description

Introducing the F4BTME298 PCB, a high-performance printed circuit board engineered for demanding applications. This PCB is constructed using advanced F4BTME laminates, which are meticulously manufactured through a specialized process that combines glass fiber cloth, nano-ceramic fillers, and polytetrafluoroethylene (PTFE) resin. The result is a substrate that excels in high-frequency performance, thermal stability, and insulation.



Key Features
Dielectric Constant (Dk): 2.98 ±0.06 at 10 GHz, ensuring superior signal integrity.
Dissipation Factor: Exceptionally low at 0.0018 at 10 GHz and 0.0023 at 20 GHz, minimizing energy loss.
Thermal Performance: Coefficient of thermal expansion (CTE) values of 15 ppm/°C (X-axis), 16 ppm/°C (Y-axis), and 78 ppm/°C (Z-axis), with operating temperatures from -55°C to 288°C.
Low Moisture Absorption: Only 0.05%, maintaining performance in humid conditions.
Passive Intermodulation (PIM): Outstanding performance with a PIM value of <-160 dBc.



Product Features Test Conditions Unit F4BTME298 F4BTME300 F4BTME320 F4BTME350
Dielectric Constant (Typical) 10GHz / 2.98 3.0 3.2 3.5
Dielectric Constant Tolerance / / ±0.06 ±0.06 ±0.06 ±0.07
Loss Tangent (Typical) 10GHz / 0.0018 0.0018 0.0020 0.0025
20GHz / 0.0023 0.0023 0.0026 0.0035
Dielectric Constant Temperature Coefficient -55 º~150ºC PPM/℃ -78 -75 -75 -60
Peel Strength 1 OZ F4BTM N/mm >1.6 >1.6 >1.6 >1.6
1 OZ F4BTME N/mm >1.4 >1.4 >1.4 >1.4
Volume Resistivity Standard Condition MΩ.cm ≥1×10^7 ≥1×10^7 ≥1×10^7 ≥1×10^7
Surface Resistivity Standard Condition ≥1×10^6 ≥1×10^6 ≥1×10^6 ≥1×10^6
Electrical Strength (Z direction) 5KW,500V/s KV/mm >26 >30 >32 >32
Breakdown Voltage (XY direction) 5KW,500V/s KV >34 >35 >40 >40
Coefficientof Thermal Expansion XY direction -55 º~288ºC ppm/ºC 15,16 15,16 13,15 10,12
Z direction -55 º~288ºC ppm/ºC 78 72 58 51
Thermal Stress 260℃, 10s,3 times No delamination No delamination No delamination No delamination
Water Absorption 20±2℃, 24 hours % ≤0.05 ≤0.05 ≤0.05 ≤0.05
Density Room Temperature g/cm3 2.25 2.25 2.20 2.20
Long-Term Operating Temperature High-Low Temperature Chamber -55~+260 -55~+260 -55~+260 -55~+260
Thermal Conductivity Z direction W/(M.K) 0.42 0.42 0.50 0.54
PIM Only applicable to F4BTME dBc ≤-160 ≤-160 ≤-160 ≤-160
Flammability / UL-94 V-0 V-0 V-0 V-0
Material Composition / / PTFE, Fiberglass Cloth, nano-ceramics
F4BTM paired with ED copper foil, F4BTME paired with reverse-treated (RTF) copper foil.



PCB Stackup Configuration
This PCB features a robust 2-layer rigid stackup:

Copper Layer 1: 35 μm
Core Material: F4BTME298 (1.524 mm / 60 mil)
Copper Layer 2: 35 μm



This configuration results in a finished board thickness of 1.6 mm, with a total copper weight of 1 oz (1.4 mils) across the outer layers.



Construction Details
Board Dimensions: 51.51 mm x 111.92 mm (±0.15 mm)
Minimum Trace/Space: 6/5 mils
Minimum Hole Size: 0.3 mm
Vias: 41 total, with no blind vias included.
Surface Finish: Immersion Tin for excellent solderability.
Silkscreen and Solder Mask: Features a white top silkscreen and a green top solder mask; no bottom silkscreen or solder mask.
Each PCB undergoes rigorous 100% electrical testing prior to shipment to ensure reliability and performance.



Quality Assurance

This PCB meets the IPC-Class-2 quality standard, ensuring high reliability for various applications.



Applications
The F4BTME298 PCB is ideal for a wide range of applications, including:



Aerospace and cabin equipment
Microwave and RF technologies
Military radar systems
Feed networks
Phase-sensitive and phased array antennas
Satellite communications



Availability

The F4BTME298 PCB is available for global, making it accessible for engineers and designers worldwide seeking high-performance solutions for their projects.



PCB Material: PTFE / glass fiber cloth / Nano-ceramic filler
Designation (F4BTME ) F4BTM DK (10GHz) DF (10 GHz)
F4BTME298 2.98±0.06 0.0018
F4BTME300 3.0±0.06 0.0018
F4BTME320 3.2±0.06 0.0020
F4BTME350 3.5±0.07 0.0025
Layer count: Single Sided, Double Sided PCB, Multilayer PCB, Hybrid PCB
Copper weight: 0.5oz (17 µm), 1oz (35µm), 2oz (70µm)
Dielectric thickness (or overall thickness) 0.25mm, 0.508mm, 0.762mm, 0.8mm, 1.0mm, 1.016mm, 1.27mm, 1.524mm, 2.0mm, 3.0mm, 4.0mm, 5.0mm, 6.0mm, 8.0mm, 10.0mm, 12.0mm
PCB size: ≤400mm X 500mm
Solder mask: Green, Black, Blue, Yellow, Red etc.
Surface finish: Bare copper, HASL, ENIG, Immersion silver, Immersion tin, OSP, Pure gold, ENEPIG etc..
