Single Sided 95x64mm Aluminium Substrate PCB Motor Driver PCB

Products

Metal Core PCB

Ms. Ivy Deng

sales10@bichengpcb.com

86-755-27374847

Contact Now

Single Sided 95x64mm Aluminium Substrate PCB Motor Driver PCB

MOQ:	1PCS
Price:	USD9.99-99.99
Standard Packaging:	Vacuum bags+Cartons
Delivery Period:	8-9 working days
Payment Method:	T/T
Supply Capacity:	5000PCS per month

Details Information

Product Description

Detail Information

Place of Origin

CHINA

Brand Name

Bicheng

Certification

UL, ISO9001, IATF16949

Model Number

BIC-778.V1.0

Base Material:

2W/MK Dielectric Material

Layer Count:

Single Side

PCB Thickness:

1.6mm ±0.16

PCB Size:

95 X 64mm=1PCS

Solder Mask:

Black

Silkscreen:

White

Copper Weight:

Surface Finish:

Hot Air Soldering

Highlight:

Single Sided Aluminium Substrate PCB

95x64mm Aluminium Substrate PCB

95x64mm Motor Driver PCB

Product Description

Single Sided Aluminum PCB 2W/MK Thermal Conductivity MCPCB With HASL for Motor Driver
(PCB’s are custom-made products, the picture and parameters shown are just for reference)

General description
This is a type of Aluminum PCB for the application of motor driver. It's a single layer MCPCB board at 1.6 mm thick with 2W/MK thermal conductivity. The aluminum plate is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated per IPC 6012 Class 2 using supplied Gerber data. 25 boards are packed separately.

Parameter and data sheet

PCB SIZE	95 x 64mm=1PCS
BOARD TYPE	Aluminum PCB, IMS PCB
Number of Layers	Single sided PCB
Surface Mount Components	YES
Through Hole Components	NO
LAYER STACKUP	copper ------- 35um(1oz)
	2W/MK dielectric material
	Aluminum 5052
TECHNOLOGY
Minimum Trace and Space:	40 mil /- mil
Minimum / Maximum Holes:	2.0 / 4.0 mm
Number of Different Holes:	2
Number of Drill Holes:	14
Thermal resistance(°C/W)	≤0.45
Breakdown Voltage(VDC)	4000
Impedance Control	no
BOARD MATERIAL
Thermal conductivity	2W/MK dielectric material, MCPCB
Final foil external:	1oz
Final foil internal:	0oz
Final height of PCB:	1.6mm ±0.16
PLATING AND COATING
Surface Finish	Hot Air Soldering
Solder Mask Apply To:	Top. 12µm Minimum.
Solder Mask Color:	Black
Solder Mask Type:	LPSM
CONTOUR/CUTTING	Routing
MARKING
Side of Component Legend	TOP
Colour of Component Legend	White
Manufacturer Name or Logo:	Marked on the board in a conductor and leged FREE AREA
VIA	no via
FLAMIBILITY RATING	UL 94-V0 Approval MIN.
DIMENSION TOLERANCE
Outline dimension:	0.0059" (0.15mm)
Board plating:	0.0030" (0.076mm)
Drill tolerance:	0.002" (0.05mm)
TEST	100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED	email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA	Worldwide, Globally.

Single Sided 95x64mm Aluminium Substrate PCB Motor Driver PCB 0

Features and benefits
SMT process
Effective heat dissipation reduces the operating temperature of the module and prolongs the service life.
Power density and reliability are improved up 10%.
Reduce the cost of hardware and assembly,
Comprehensive equipment management and maintenance and process control,
1-10 pieces are offered for sale.
International approvals

Applications
Power amplifier,
Motor driver,
Power supply device,
Fluorescent lamp
