Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production

Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production
Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production

Large Image :  Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production

Product Details:
Place of Origin: CHINA
Brand Name: Bicheng
Certification: UL, ISO9001, IATF16949
Model Number: BIC-299.V1.0
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD9.99-99.99
Packaging Details: Vacuum bags+Cartons
Delivery Time: 8-9 working days
Payment Terms: T/T
Supply Ability: 5000PCS per month
Detailed Product Description
Base Material: Polyimide Layer Count: 1 Layer
PCB Thickness: 0.15mm +/-10% Coverlay: Yellow
Silkscreen: White Copper Weight: 1oz
Surface Finish: Immersion Gold



Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production

(Flexible printed circuits are custom-made products, the picture and parameters shown are just for reference)



General description

This is a type of flexible printed circuit for the application of antenna. It’s a single layer board at 0.15mm thick. The base laminate is from ITEQ, It’s fabricated per IPC 6012 Class 2 using supplied Gerber data. 3M tape is applied on the back side, Polyimide as stiffener on the head.



Parameter and data sheet

Number of Layers 1
Board Type Flexbile cirucit
Board Thickness 0.15mm +/-10%
Board Material Polyimide (PI) 25um
Board Material Supplier ITEQ
Tg Value of Board Material 60℃

PTH Cu thickness N/A
Inner Iayer Cu thicknes N/A
Surface Cu thickness 35 um (1oz)

Coverlay Colour Yellow
Number of Coverlay 2
Thickness of Coverlay 25 um
Stiffener Polyimide 0.3mm

Type of Silkscreen Ink Taiyo
Supplier of Silkscreen Taiyo
Color of Silkscreen White
Number of Silkscreen 1

Mininum Trace (mil) 20 mil
Minimum Gap(mil) N/A

Surface Finish Immersion Gold
RoHS Required Yes
Famability 94-V0

Thermal Shock Test Pass, -25℃±125℃, 1000 cycles.
Thermal Stress Pass, 300±5℃,10 seconds, 3 cycles. No delamination, no blistering.
Function 100% Pass electrical test
Workmanship Compliance with IPC-A-600H & IPC-6013C Class 2



Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production 0



Features and benefits

Excellent flexibility

Reducing the volume

Weight reduction

Consistency of assembly

Increased reliability

Controllability of electrical parameter design

The end can be whole soldered

Continuity of processing

Competitive price

Quick Lead time: 3-5 days



Applications

Thin-film switch, Mobile phone battery flex board, medical keypad soft board



Clarifications of FPC

According to the combination of base material and copper foil, flexible circuit board can be divided into two types: flexible board with adhesive and flexible board without adhesive. The price of non-adhesive flexible PCB is much higher than that of adhesive flexible PCB, but its flexibility, bonding force between copper foil and substrate and flatness of solder are also better than that of adhesive flexible PCB. So it is only used in the high demand situations, such as the: COF (CHIP ON FLEX, flexible board with bare chip, the high flatness of the pad) and so on. Because its price is high, most of the flexible PCBs used in the market are still adhesive flexible circuit board. Because the flexible circuit board is mainly used in the situation where bending is required, if the design or process is not reasonable, it is easy to produce micro-cracks, welding and other defects.



Economy of using FPC

If the circuit design is relatively simple, the total volume is small, and the space is suitable, the traditional internal connection is much cheaper. Flexible circuits are a good design option if the circuit is complex, processes many signals or has special electrical or mechanical requirements. When the size and performance of applications exceed the capacity of rigid circuits, flexible assembly is the most economical. A 12mil pad with a 5mil through hole and a flexible circuit with 3mil lines and spacing can be fabricated on a thin film. Therefore, it is more reliable to mount the chip directly on the film. There is no flame retardant that could be an ion source. These films may be protective and solidified at higher temperatures to obtain higher glass transition temperatures. Flexible materials are less costly than rigid materials because they are free of connectors.



Single Sided Antenna Flexible PCB on Polyimide With Immersion Gold and 3M Tape and PI Stiffener Supplied Mass Production 1
