RT / Duroid 5880 RF PCB Board For High Frequency Applications

Hi, today's topic is introducing our newly shipped PCB product. This double sided PCB is constructed from high-quality Rogers RT/duroid 5880 material, making it ideal for high-frequency applications. It features a lead-free process, ensuring its compatibility with modern manufacturing standards.

The PCB stack-up consists of two layers of base copper with a thickness of 17um, separated by a 5mil RT/duroid 5880 dielectric layer. The board dimensions measure 7mm x 7mm with a tolerance of +/- 0.15mm. With a minimum trace/space of 4/4 mils and a minimum hole size of 10 mils, this PCB is suitable for a variety of applications.

This product does not include silkscreen or solder mask, and it's finished with a thickness of 0.197mm and a 1 oz (1.4 mils) copper weight on all layers. It has been fully tested for quality assurance, including a 100% electrical test.

This PCB supports one component and has a total of two pads, one via, and one net. It is suitable for through-hole and top surface mount component placement.

For any technical questions about this product, please do not hesitate to contact our sales team at sales10@bichengpcb.com. Bicheng Limited. reserves all rights to this product, copyright 2023

RT/Duroid 5880: The Ultimate Solution for High-Frequency PCB Design

--RT/Duroid 5880 for High-Speed Data Transmission

The search for high-performance materials that can meet the demands of high-frequency PCB design has led to the discovery of RT/Duroid 5880. This remarkable double-sided PCB material, manufactured by Rogers Corporation, is made from a blend of PTFE and ceramic materials, which gives it superior electrical and mechanical properties. Here is an overview of its properties and applications.

Overview of RT/Duroid 5880:

RT/Duroid 5880 is a cutting-edge material that has been designed to meet the demands of high-frequency applications. Its low dielectric constant and low dissipation factor make it the ideal choice for high-frequency applications, where signal loss and distortion can be significant issues. The material is also compatible with lead-free processes, which makes it an eco-friendly option for PCB manufacturing.

Dielectric Properties of RT/Duroid 5880:

The low dielectric constant of RT/Duroid 5880, which ranges from 2.20 to 2.22 depending on the frequency, is one of its most significant advantages. This makes it an ideal material for high-frequency applications, where signal loss and distortion can be major issues. The material also has a low dissipation factor, which ensures that the signals remain clear and accurate.

Comparing RT/Duroid 5880 to Other PCB Materials:

When compared to other PCB materials such as FR-4 and polyimide, RT/Duroid 5880 stands out for its superior electrical properties. Its low dielectric constant and dissipation factor make it the best choice for high-frequency applications. It also has excellent mechanical properties, with high tensile and compressive strength, making it a durable option for PCBs.

Thermal and Mechanical Properties of RT/Duroid 5880:

RT/Duroid 5880 has a low thermal coefficient of ε, which means that it experiences minimal changes in dielectric constant with temperature. It also has a high glass transition temperature (Td) of 500℃, which means that it can withstand high temperatures without losing its mechanical properties.

Applications of RT/Duroid 5880:

RT/Duroid 5880 is a versatile material that can be used in a wide range of applications, including aerospace, defense, telecommunications, and automotive industries. Its low dielectric constant and dissipation factor make it ideal for high-frequency applications, such as microwave and millimeter-wave circuits, antennas, and filters. Its mechanical properties also make it a suitable material for use in high-stress environments.

Designing PCBs with RT/Duroid 5880:

Designing PCBs with RT/Duroid 5880 requires special considerations, such as the need for smaller trace widths and spacing to account for the material's low dielectric constant. However, the benefits of using RT/Duroid 5880, such as reduced signal loss and distortion, make it a worthwhile investment for high-frequency applications.

RT/Duroid 5880 for High-Speed Data Transmission:

RT/Duroid 5880 is the material of choice for achieving maximum data rates. Its low dielectric constant and loss tangent make it suitable for use in high-speed digital circuits, such as those used in 5G networks and internet of things (IoT) devices.

Lead-Free Process Compatibility of RT/Duroid 5880:

RT/Duroid 5880 is compatible with lead-free processes, which means that it meets modern manufacturing standards and is an eco-friendly option for PCB manufacturing. This makes it a popular choice for companies looking to reduce their carbon footprint and comply with environmental regulations.

Testing and Quality Control of RT/Duroid 5880 PCBs:

RT/Duroid 5880 PCBs undergo rigorous testing and quality control to ensure that they meet the highest standards of performance and reliability. This includes a 100% electrical test to verify the integrity of the circuits and ensure that they are free from defects.

Conclusion:

In summary, RT/Duroid 5880 is a cutting-edge material that offers superior electrical and mechanical properties. Its low dielectric constant and dissipation factor make it the ideal choice for high-frequency applications, and its compatibility with lead-free processes makes it an eco-friendly option for PCB manufacturing. With its high-quality testing and quality control processes, RT/Duroid 5880 is the ultimate solution for companies looking to design high-performance and reliable PCBs.
